Underneath spindle oilers (also called side oilers) feed oil to a reservoir, from where wicks lift and filter it into the ideal position below the spindle - where bearing clearance will be at its maximum during heavy cutting. Spindle is highly finished steel running in the cast iron of the headstock - no bronze or white metal here. Later Heavy 10s can have bearing caps with four holding down screws
